SondaSys LA1100 dual

Sondasys LA 1100 dual

Stereolithography is one of the additive manufacturing technologies, consisting in hardening of specialized resins using a UV laser beam. The laser dot harden the outside edges of the detail and then fill them, creating a spatial model layer by layer in this way. A characteristic feature of the parts made in this technology are extremely smooth surfaces of models. 3D resin printers also allow you to make details with high precision of small details (precision reaches up to 0.05 mm).

Technical specification:

Working chamberDimensions1000x1000x600 mm (standard)
  1000x1000x400/500 mm (custom)
 Resin heating systemHot air
 Available materialsZR680, ZR710, ZR820, RealABS, RedWood
 Operating systemWindows 7
Physical propertiesDimensions1600 x 1900 x 2300 mm
 Weight~1800 kg
 Working temperature20-26 ºC
 Power supply200~240 VAC,
  50/60 Hz
  1 phase, 5/17 A
OpticsLaser type:Nd:YVO4
 Laser beam diameter (1/e2)0.1~0.16 mm (normal) 0.1~0.5mm (super)
 Wavelenght354,7 nm
 Power1000 mW/3000 mW
 Detail scanning speed6.0 m/s
 Scanning speed10.0 m/s
 Model building speed100~230 g/h (super), 200~450 g/h (x2 double galvo)
TolerancesPositioning repeatability+/- 0,01 mm
 Layer thicknessStandard: 0,1 mm
  Fast: 0,1-0,15 mm
  Precise: 0,05-0,1 mm
OtherConnectionEthernet, TCP/IP, IEEE802.3
 SoftwareSondasys SLA1100
 File formatCLI, SLC, STL
WarrantyLaser12 months or 5000 working hours
 Machine12 months
